DIN 3062 8x19S FC IWR Galvanized Elevator Steel Wire Rope
Manufactured and inspected under one roof in Shaoxing, Zhejiang — an 8,700 m² factory running an ISO 9001 quality system. Batch tested to the specification you agree, with full export documents.
- Item No.
- 287
- Material
- Galvanized steel
- Quality & standards
- Mill certificate and tensile report supplied on request
- Category
- Wire Rope
- Customisation
- Diameter, construction, lay, core, finish and length to your specification
- MOQ
- Negotiable — trial orders and mixed containers accepted
Or email sales@chinacargocontrol.com — mention the item number and we will reply within 2 working hours.
Product overview
The DIN 3062 elevator steel wire rope is manufactured with high precision to ensure safety, durability, and smooth performance in lifting applications.
It is available in different constructions, including 8x19S+FC, 8x19S+IWR, and 8x19W, with options of fiber core (FC) or independent wire rope core (IWR).
Features: Manufactured according to DIN 3062 standard for elevator use High tensile strength and excellent flexibility Galvanized surface for enhanced corrosion resistance and longer service life Smooth running and stable performance under heavy loads Available with fiber core (FC) or independent wire rope core (IWR)
Which standard applies in your market
The same product is rated and marked differently in each market. In Europe and Australia a lifting sling is rated by its safety factor (7:1) and a lashing by its Lashing Capacity (LC); in North America the same product is marked with a Working Load Limit (WLL) on a 5:1 design factor. Tell us your destination market and the end use, and we build to the standard your buyer specifies — with the matching test certificate, marking and documentation.
| European Union / UK | EN 13414-1 (slings) · EN 12385 (rope) — Steel wire rope slings — working coefficient 5 |
|---|---|
| United States | ASME B30.9 — Wire rope slings — design factor 5:1 |
| Australia / New Zealand | AS 1666.1 / AS 1666.2 — Wire-rope slings — product specification and care and use |
Reference for quotation: Item No. 287. Quote this and we come straight back with price, MOQ and lead time.
Specification & ordering
| Item No. | 287 |
|---|---|
| Material | Galvanized steel |
| Quality & standards | Mill certificate and tensile report supplied on request |
| Category | Wire Rope |
| Customisation | Diameter, construction, lay, core, finish and length to your specification |
| MOQ | Negotiable — trial orders and mixed containers accepted |
| Sample | Free sample for evaluation, freight collect |
| Lead time | 10–50 days depending on quantity (confirmed at order) |
| Port | Ningbo / Shanghai, China |
